Why Your Gravel Driveway is Washing Out in West Virginia

A gravel driveway should not have to be replaced every time it rains.

Every time you add gravel, fill ruts, replace low spots, or push the stone back up the driveway, something larger is going on below the surface.

In most cases, the culprit is not the gravel itself, but the water

Around Beckley, Glen Daniel, Raleigh County, and the Southern WV region, gravel driveways are subjected to constant stress. Slopes, clay, inadequate ditches, and

improper culvert installation or grading all play a role in washouts. Once water finds a path down a driveway, it will continue to use that path until it exits the

property.

Built Right Construction Inc. provides excavation, grading, drainage, driveway,

septic, and site preparation services throughout Southern WV. If your gravel

driveway keeps washing out, these are the potential causes, and what will

actually need to be done to stop it.

The real reasons gravel driveways wash out

A gravel driveway washout happens when water takes a path across or down the

driveway, eroding the surface and carrying gravel away with it.

This can occur due to large storms, but the process usually begins long before

the damage becomes apparent. Water will begin to undercut the gravel on a

slope or along the edge and form small ruts. Once these ruts connect to form a

channel, water will have a preferred path down the driveway.

The EPA defines stormwater runoff as "rainwater or snow melt from developed or

vegetated land that does not infiltrate the ground..." Runoff often carries sediment

with it and contributes to erosion issues if not properly handled.

On a gravel driveway, this sediment is frequently the gravel that makes up the

driveway surface, washing away one storm at a time.

Cause 1: Water is running down the driveway

This is a common issue on sloped properties

If the driveway is acting as a channel for water, it will wash out repeatedly. Water

will flow down the driveway following the wheel tracks, low spots, and other weak

areas. The faster it is able to flow, the more material it will carry with it.

Watch for:

• Ruts running the length of the driveway

• Gravel at the bottom of the slope

• Exposed dirt or clay

• Channels that begin as small ruts and grow larger with each storm

• Loosened stone on one side of the driveway

While filling ruts and adding gravel may make the driveway look nice for a while, the problem will persist if the water continues to flow down the driveway.

For an in-depth discussion about the difference between excavation and

grading, see our post about excavation vs grading in WV.

Cause 2: The driveway does not have the proper crown

A crowned driveway allows water to run off the edges and prevents it from

pooling in the center. If the driveway is crowned incorrectly, water will run off to

one side, creating large puddles or damaging the shoulder. A crowned driveway

allows for proper drainage and reduces the chances of erosion.

The FHWA recommends proper drainage for gravel roads because "it improves

safety and drainage, facilitates year-round use..., reduces slipperiness,

minimization of ruts and potholes."

Proper drainage also extends the lifespan of a gravel driveway, preventing

erosion of the base materials and washouts.

Cause 3: The ditches are not handling the water properly

Driveway ditches are often an overlooked area on a property, but they serve an

essential function. On many properties in WV, the ditches are the only things

preventing driveway washouts.

A properly sized, cleaned, and graded ditch will carry water away from the

driveway. An undersized or plugged ditch will allow water to run down the

driveway, eroding the gravel and exposing dirt or clay.

Look for:

• Water running alongside the driveway instead of into the ditch

• Leaves, mud, or debris blocking the ditch

• Water crossing the driveway consistently

• Soft, eroded driveway shoulders

• A ditch that ends abruptly, without a stable outlet

The problem with the ditch may not be apparent at first, and the driveway washout may seem like the bigger problem

Cause 4: The culvert is clogged, undersized, or damaged

A culvert is a pipe that allows water to flow underneath the driveway. When a

culvert works properly, it prevents water from eroding the driveway. If the culvert

becomes clogged or damaged, water will flow over or around it, causing a

washout

A faulty culvert will lead to a number of issues, including:

• Puddling on one side of the driveway

• Water flowing over the driveway surface

• Erosion around the culvert

• Water cutting into the driveway where the culvert enters or exits

The FHWA describes culverts as "drainage structures placed beneath a driveway or road crossing..." and notes that they are necessary for a number of reasons.

If the culvert is the source of the problem, this article about driveway culvert replacement in WV explains the warning signs and the replacement options.

Cause 5: The base was not installed correctly

A gravel driveway should be built with a solid base of compacted gravel. In some

cases, the base is not built with the proper materials or compaction, leaving the

driveway vulnerable to erosion. Water will accelerate this process, especially if the

base was built on top of loose soil.

Watch for:

• Soft spots after rain

• Ruts that quickly fill with water and erode

• Puddles or mud pumping up through the gravel

• Gravel pulling out of the ground

• Uneven patches that settle differently after rain

A weak base can cause repeated washouts, requiring the entire driveway to be reconstructed. Adding gravel on top of a weak base is often a temporary fix that only lasts until the next storm

Cause 6: Water from other areas is crossing the driveway

Many driveway washouts in Southern WV are the result of water crossing the

driveway from a different source. Water may be flowing down a slope, across the

driveway from a yard, or flowing out of a ditch or downspout.

The National Weather Service warns that "floods can occur anywhere in the U.S.,

but flash flooding is more common in the West and Midwest...caused by heavy

rainfall in steep, mountainous areas..."

Driveways on sloped properties need more than just gravel, especially in mountainous areas. In many cases, the entire driveway needs to be regraded, or other drainage features installed to handle the water flow

If water from the roof, a neighboring property, or other areas around the home are contributing to the issue, this article about signs you need regrading around your home in WV may be helpful.

Cause 7: Water does not have a stable exit

Even with ditches and culverts, water needs a stable place to exit the property.

If the water is flowing too quickly, into soft ground, or over exposed roots, it can

erode the ground underneath the driveway, culvert, or ditch. This can cause

washouts in the driveway or along the ditch banks. In some cases, additional rock

or proper grading is needed to slow the flow or protect the bank.

This topic was discussed in more detail in this article about erosion control for WV

properties.

What not to do when a gravel driveway washes out

Do not continue to add gravel until the water has been redirected.

Do not repeatedly fill ruts if the water is flowing down the driveway.

Do not block the flow of water if it has nowhere else to go.

Do not ignore clogged ditches, faulty culverts, or the effects of erosion.

Do not direct water toward your home, septic, or your neighbor's property.

Do not assume that the driveway needs to be replaced if the grade or drainage is

the real issue.

Repeat washouts occur when the visible problems are patched, but the source of

the issue is ignored.

What a long-term repair should include

The repair process should always begin with finding the source of the water and

where it is going. In many cases, a combination of grading and drainage

techniques will be required to stop the erosion. This may include reshaping the

crown, rebuilding the base, repairing or replacing ditches, and replacing a faulty

culvert. It may also include adding stone to stabilize the flow, or directing the

water elsewhere so that it does not flow down or across the driveway.

In many cases, the best repair option is to combine grading and drainage to stop

the erosion.

That is why we always inspect the entire property when repairing a washed-out

gravel driveway. A grade or drainage issue may exist at the top, middle, or

bottom of the driveway.

What factors affect gravel driveway washout repair costs?

The cost of a repair always depends on the extent of the damage and what

needs to be done.

The length, slope, and access to the driveway are all a factor, as is the condition

of the existing base materials. The amount of gravel needed, ditch repairs, culvert

replacement, drainage issues, and outlet protection also impact the cost. The

removal of unsuitable materials and excavation costs also play a role. A simple

surface repair is much different than addressing a steep driveway with failed

ditches, culverts, and base materials.

While simple repairs may have a lower cost, they may also fail again in the same

spot.

What to expect when Built Right repairs a gravel driveway

By looking at a gravel driveway, we can evaluate the entire drainage process.

We always consider the slope, crown, ditches, culverts, and driveway shoulders.

We also look at where the water is coming from and where it is going. We will

explain what needs to be done to ensure that the repairs actually last. In many

cases, this means grading and adding gravel, but it could also include rebuilding

the base, repairing or replacing ditches, culverts, or adding erosion control at the

outlet. We want to make sure the driveway is not just pretty, but fit for the weather

in Southern WV.

FAQ: Gravel driveway washout and erosion in WV

Why is my gravel driveway washing out every time it rains?

Your driveway is washing out because it is acting as a channel for water. Water

will always find the path of least resistance, and that frequently means the

driveway. In most cases, the grading, ditches, or culverts need to be repaired or

replaced so that the water has a different path.

Will adding more gravel fix a washed out gravel driveway?

In some cases, adding gravel can help fill ruts and depressions, but it will not stop

the water from flowing down the driveway.

Does my gravel driveway need a crown?

Most gravel driveways should have a slight crown so that water runs off either

side. Without a crown, water will accumulate in the center of the driveway,

creating large puddles and soft spots.

How do I know if my culvert is causing my driveway to washout?

If water is accumulating on one side of the driveway, or flowing over the surface,

the culvert may be clogged, undersized, or installed incorrectly.

Can grading fix a washed out gravel driveway?

The driveway may need to be graded so that the water flows off to the sides

instead of across the surface.

Why does gravel collect at the bottom of my driveway?

Gravel at the bottom of the driveway is frequently the result of water flowing

down the driveway, eroding the gravel surface.
